Though the specified capacity & stroke of the jacks are designed for maximum safe working, we recommend to use the jacks for 85% of its rated capacity & stroke as safe working practice and for long life of the jacks.
Ultra Low Height Plain Ram Spring Return Hydraulic Flat Jacks( FJS Series )
Capacity : 5-200, Stroke : 8-16 mm, Working : 700 bar (Max)
Features / Benefits
Compact, Flat design, High strength, heat treated alloy steel body
Hard chrome plated ram to resist scoring & corrosion.
Single acting, spring return for smooth lowering. High pressure long life seals.
Top mounting holes for easy fixturing. Grooved ram acts as integral saddle.
'O' Ring to arrest ingress of foreign particles.
Poet Size 1/4th Inch or 3/8" NPT.
QCC with Plastic dust cap. Aluminium dust cap on request.
Technical Specification
MODEL NO. |
Capacity |
Closed Ht. 'CH' |
Stroke 'S' |
Ram Dia 'RD' |
Outer
Dia 'D' |
Oil Volume |
Approx Weight |
Suitable
Hand Pump |
tons. |
mm. |
mm. |
mm. |
mm. |
cc. |
kgs. |
||
FJS 5/8 |
5 |
35 |
8 |
25 |
60 x 45 |
7.2 |
0.5 |
PHP 200 / 2 |
FJS
5/16 |
5 |
43 |
16 |
25 |
60 x 45 |
12.9 |
1.0 |
PHP 200 / 2 |
FJS 10/12 |
10 |
45 |
12 |
38 |
80 x 60 |
19 |
1.3 |
PHP 200 / 2 |
FJS
20/12 |
20 |
51 |
12 |
50 |
100 x 80 |
40.5 |
2.6 |
PHP 200 / 2 |
FJS
30/12 |
30 |
58 |
12 |
65 |
117 x 95 |
57.5 |
3.0 |
PHP 200 / 2 |
FJS
50/16 |
50 |
65 |
16 |
70 |
140 x 120 |
113.5 |
6.0 |
PHP 400 / 3N |
FJS
75/16 |
75 |
79 |
16 |
85 |
175 x 145 |
203.5 |
11.6 |
PHP 400 / 3N |
FJS
100/16 |
100 |
85 |
16 |
100 |
185 x 160 |
257 |
17.1 |
PHP 400 / 3N |
FJS
150/16 |
150 |
85 |
16 |
120 |
230 x 205 |
408.5 |
29.5 |
PHP 400 / 3N |
FJS
200/16 |
200 |
115 |
16 |
140 |
265 x 230 |
510.3 |
45.0 |
PHP 400 / 3N |
 |
 |
