Though the specified capacity & stroke of the jacks are designed for maximum safe working, we recommend to use the jacks for 85% of its rated capacity & stroke as safe working practice and for long life of the jacks.
Plain Ram, Springs Return Hdraulic Jacks (LPS-Series)
Capacity : 5 - 500 tons, Stroke : 50 - 150 mm, Working : 700 bar (Max)
Features / Benefits
Hight strength, Heat treated alloy steel body
Hard chrome plated ram to resist scoring and corrosion.
Single acting spring return for smooth lowering.
High pressure long life seals.
Wiper to arrest ingress of foreign particles.
Bootom mounting holes for bolting.
Adequate gripping by grooved saddle.
Port Sixe 3/8" NPT.
Customised capacity, strokes, Collar threading and tilting saddle available on request.
QCC with Plastic dust cap. Aluminum dust cap on request.
Applications
These jacks are an excellent choice for maintenance, positioning, bending, pressing, ideal for wide range of applications at construction site, mills, railway workshops, power plants and industrial maintenance.
MODEL NO. |
Capacity |
Closed Ht. 'CH' |
Stroke 'S' |
Ram Dia 'RD' |
Outer Dia 'D' |
Oil Volume |
Approx Weight |
Suitable Hand Pump
|
tons. |
mm |
mm |
mm |
mm |
cc |
kgs. |
||
LPS10/50 |
10 |
140 |
50 |
38 |
65 |
88 |
3 |
PHP 200/2 |
LPS10/100 |
10 |
190 |
100 |
38 |
65 |
164 |
3.5 |
PHP 200/2 |
LPS 10/150 |
10 |
240 |
150 |
38 |
65 |
243 |
4.9 |
PHP 200/2 |
LPS 15/50 |
15 |
150 |
50 |
45 |
70 |
131 |
3.5 |
PHP 200/2 |
LPS 15/100 |
15 |
200 |
100 |
45 |
70 |
247 |
4.6 |
PHP 200/2 |
LPS 15/150 |
15 |
250 |
150 |
45 |
70 |
366 |
5.2 |
PHP 200/2 |
LPS-20/50 |
20 |
160 |
50 |
50 |
80 |
155 |
4.9 |
PHP 200/2 |
LPS 20/100 |
20 |
210 |
100 |
50 |
80 |
324 |
5.7 |
PHP 200/2 |
LPS 20/150 |
20 |
260 |
150 |
50 |
80 |
480 |
7.1 |
PHP 200/3 |
LPS 25/50 |
25 |
170 |
50 |
60 |
90 |
156 |
6.8 |
PHP 200/2 |
LPS 25/100 |
25 |
220 |
100 |
60 |
90 |
404 |
8.2 |
PHP 200/3 |
LPS 25/150 |
25 |
270 |
150 |
60 |
90 |
596 |
10.2 |
PHP 200/3 |
LPS 30/50 |
30 |
170 |
50 |
65 |
100 |
251 |
8.0 |
PHP 200/3 |
LPS 30/100 |
30 |
220 |
100 |
65 |
100 |
528 |
10.5 |
PHP 200/3 |
LPS 30/150 |
30 |
270 |
150 |
65 |
100 |
779 |
14.5 |
PHP 200/3 |
LPS 50/50 |
50 |
185 |
50 |
80 |
130 |
425 |
17.0 |
PHP 500/3 |
LPS 50/100 |
50 |
235 |
100 |
80 |
130 |
817 |
19.4 |
PHP 500/6 |
LPS 50/150 |
50 |
285 |
150 |
80 |
130 |
1209 |
22.5 |
PHP 500/6 |
LPS 75/50 |
75 |
200 |
50 |
95 |
155 |
622 |
23.0 |
PHP 500/6 |
LPS 75/100 |
75 |
250 |
100 |
95 |
155 |
1188 |
28.5 |
PHP 500/6 |
LPS 75/150 |
75 |
300 |
150 |
95 |
155 |
1753 |
32.5 |
PHP 500/6 |
LPS 100/50 |
100 |
215 |
50 |
120 |
175 |
830 |
36.05 |
PHP 500/6 |
LPS 100/100 |
100 |
265 |
100 |
120 |
175 |
1616 |
40.6 |
PHP 500/6 |
LPS 100/150 |
100 |
315 |
150 |
120 |
175 |
2386 |
47.3 |
PHP 500/6 |
LPS 150/100 |
150 |
275 |
100 |
140 |
226 |
2383 |
65.0 |
PHP 500/6 |
LPS 150/150 |
150 |
325 |
150 |
140 |
226 |
3518 |
75.0 |
PHP 500/12 |
LPS 200/100 |
200 |
290 |
100 |
160 |
256 |
3141 |
88.0 |
PHP 500/12 |
LPS 200/150 |
200 |
340 |
150 |
160 |
256 |
4874 |
100.0 |
PHP 500/12 |
LPS 250/100 |
250 |
295 |
100 |
180 |
286 |
3991 |
115.0 |
PHP 500/12 |
LPS 250/150 |
250 |
345 |
150 |
180 |
286 |
5892 |
131.0 |
PHP 500/12 |
LPS 300/100 |
300 |
310 |
100 |
200 |
315 |
4746 |
148.0 |
PHP 500/12 |
LPS 300/150 |
300 |
360 |
150 |
200 |
315 |
7012 |
167.0 |
PHP 500/20 |
LPS 400/100 |
400 |
330 |
100 |
220 |
355 |
6465 |
200.0 |
PHP 500/20*PP |
LPS 400/150 |
400 |
380 |
150 |
220 |
355 |
9544 |
225.0 |
PHP 500/20*PP |
LPS 500/100 |
500 |
350 |
100 |
250 |
405 |
7925 |
281.2 |
PHP 500/20*PP |
LPS 500/150 |
500 |
400 |
150 |
250 |
405 |
11700 |
315.0 |
PHP 500/20*PP |
*PP - Power Pack
 |
 |
