Aluminium Threaded Ram, Hydraulic Jacks (ATS-Series)
Capacity : 20-200 tons, Stroke : 100-150 mm, Working : 700 bar (Max)
Model No. |
Capacity |
Closed Ht. 'CH' |
Stroke 'S' |
Ram Dia "RD' |
Outer Dia.'D' |
Oil Volume |
Approx Weight |
Suitable Hand Pump |
tons. |
mm. |
mm. |
mm. |
mm. |
cc. |
kg. |
||
ATS-20/100 |
20 |
250 |
100 |
55 |
95 |
324 |
5.5 |
PHP-200/2 |
ATS-20/150 |
20 |
300 |
150 |
55 |
95 |
480 |
6.8 |
PHP-200/3 |
ATS-30/100 |
30 |
300 |
100 |
70 |
105 |
528 |
7.8 |
PHP-200/3 |
ATS-30/150 |
30 |
350 |
150 |
70 |
105 |
779 |
10.0 |
PHP-200/3 |
ATS-50/100 |
50 |
300 |
100 |
85 |
140 |
870 |
13.5 |
PHP-500/6 |
ATS-50/150 |
50 |
350 |
150 |
85 |
140 |
1209 |
16.0 |
PHP-500/6 |
ATS-100/100 |
100 |
250 |
100 |
120 |
195 |
1616 |
27.0 |
PHP-500/6 |
ATS-100/150 |
100 |
400 |
150 |
120 |
195 |
2386 |
30.0 |
PHP-500/6 |
ATS-150/100 |
150 |
380 |
100 |
140 |
235 |
2383 |
37.0 |
PHP-500/6 |
ATS-150/150 |
150 |
430 |
150 |
140 |
235 |
3518 |
43.8 |
PHP-500/12* |
ATS-200/100 |
200 |
400 |
100 |
160 |
280 |
3300 |
58.0 |
PHP-500/12* |
ATS-200/150 |
200 |
450 |
150 |
160 |
280 |
4874 |
65.0 |
PHP-500/12* |
*PP-Powerpack |
||||||||
Features / Benefits :
- High strength, light metal Aluminium alloy body for longevity.
- Bore is roller burnished for work hardened smooth surface.
- Sliding part, i.e. the ram is hard anodized for scratch resistance.
- Single acting, plain ram, spring return design for self-lowering
- Scraper / wiper to arrest ingress of foreign particles.
- Replaceable hardened steel saddle to prevent denting & bulging of ram head.
- Larger steel base for stability.
- Ergonomic handles to ease handling.
- Bottom mounting holes meant for fixturing the steel base & not to be removed.
- Golden ring prevents overshoot of ram. Golden ring withstands full load of the jack.
- Customised Higher capacity, strokes available on request.
- Quick connect couplers with plastic dust caps. Aluminium dust cap on request.
- Port size 3/8th inch NPT.
Application
For Lifting loads at elevated location where weight of the jack is a concern and lifted load is kept for longer period.These jacks are for maintenance purpose only and not for production.
