Though the specified capacity & stroke of the jacks are designed for maximum safe working, we recommend to use the jacks for 85% of its rated capacity & stroke as safe working practice and for long life of the jacks.
Low Height, Spring Return Hydraulic Jacks (LHJ-Series)
Capacity :10-200 tons, Stroke : 25 - 60 mm, Working : 700 bar (Max)
Features / Benefits
Compact design, high strength heat treated alloy steel body.
Hard chrome plated ram to resist scoring and corrosion.
Single acting spring return for smooth lowering. High pressure long life seals.
Bottom mounting holes for bolting. Grooved ram acts as integral saddle.
Wiper to arrest ingress of foreign particles.
Port Size 3/8" NPT.
QCC with Plastic dust cap. Aluminum dust cap on request.
Application
FJS & LHS jacks are designed specifically where space is a constraint. Ideally used where no other cylinders fit for lifting, lowering, spreading of structures, bridges, cranges, heavy machinery etc.
MODEL NO. |
Capacity |
Closed Ht. 'CH' |
Stroke 'S' |
Ram Dia 'RD' |
Outer Dia 'D' |
Oil Volume |
Approx Weight |
Suitable Hand Pump |
tons. |
mm. |
mm. |
mm. |
mm. |
cc. |
kgs. |
||
LHJ 10/25 |
10 |
75 |
25 |
38 |
65 |
43 |
2.0 |
PHP 200/2 |
LHJ 10/50 |
10 |
100 |
50 |
38 |
65 |
83 |
3.0 |
PHP 200/2 |
LHJ 20/25 |
20 |
80 |
25 |
50 |
85 |
81 |
3.4 |
PHP 200/2 |
LHJ 20/50 |
20 |
105 |
50 |
50 |
85 |
159 |
308 |
PHP 200/2 |
LHJ 30/25 |
30 |
80 |
25 |
065 |
100 |
120.3 |
4.8 |
PHP 200/2 |
LHJ 30/50 |
30 |
110 |
50 |
065 |
100 |
230 |
6.1 |
PHP 200/2 |
LHJ 30/62 |
30 |
117 |
62 |
065 |
100 |
280 |
7.2 |
PHP 200/2 |
LHJ 50/60 |
50 |
122 |
60 |
090 |
130 |
480 |
11.0 |
PHP 400/3N |
LHJ 75/60 |
75 |
138 |
60 |
100 |
155 |
710 |
17.5 |
PHP 400/3N |
LHJ 100/60 |
100 |
142 |
60 |
120 |
175 |
950 |
23.5 |
PHP 500/6 |
LHJ 150/60 |
150 |
175 |
60 |
150 |
225 |
1430 |
36.0 |
PHP 500/6 |
LHJ 200/60 |
200 |
200 |
60 |
160 |
255 |
1980 |
62.3.0 |
PHP 500/6 |
 |
 |
