Though the specified capacity & stroke of the jacks are designed for maximum safe working, we recommend to use the jacks for 85% of its rated capacity & stroke as safe working practice and for long life of the jacks.
Plain Ram Load Return Hydraulic Pancake Jacks ( PCP Series )
Capacity : 10-300 tons, Stroke : 20 mm, Working Pr : 700 bar ( Max. )
Features / Benefits :
Compact, pancake design, heat treated alloy steel body.
Hard chrome plated ram to resist scoring and corrosion.
Single acting, load return, Plain Ram.
Grooved ram acts as integral saddle
High pressure long life seals.
Port Size 1/4" and 3/8" NPT.
QCC with plastic dust cap. Aluminium Dust Cap on Request.
Customised capacity and stroke on request
Application :
Pancake Jacks are designed specifically where space is a constraint. Ideally used where no other cylinders fits for lifting, lowering, spreading of structures, bridges, heavy machinery etc.
MODEL NO. |
Capacity |
Closed Ht. 'CH' |
Stroke 'S' |
Ram Dia 'RD' |
Outer Dia 'D' |
Oil Volume |
Approx Weight |
Suitable Hand Pump |
tons. |
mm. |
mm. |
mm. |
mm. |
cc. |
kgs. |
||
PCP 10/020 |
10 |
40 |
20 |
45 |
85 |
40.5 |
1.6 |
PHP 200/2 |
PCP 20/020 |
20 |
45 |
20 |
63 |
100 |
80 |
2.5 |
PHP 200/2 |
PCP 30/020 |
30 |
50 |
20 |
75 |
110 |
113 |
3.5 |
PHP 200/2 |
PCP 50/020 |
50 |
60 |
20 |
100 |
140 |
200 |
6.8 |
PHP 200/2 |
PCP 100/020 |
100 |
80 |
20 |
140 |
176 |
395 |
15 |
PHP 200/2 |
PCP 150/020 |
150 |
85 |
20 |
170 |
225 |
580 |
25 |
PHP 400/3N |
PCP 200/020 |
200 |
90 |
20 |
200 |
255 |
800 |
35 |
PHP 400/3N |
PCP 300/020 |
300 |
100 |
20 |
240 |
310 |
1150 |
60 |
PHP 400/3N |
To reduce the closed height of the jack, there is no seal box. One has to monitor the lifting stroke since there would be a chance of ram coming out of the cylinder which would result in a accident and failure of jack. Place rigid base below the jack.
 |
 |
