Though the specified capacity & stroke of the jacks are designed for maximum safe working, we recommend to use the jacks for 85% of its rated capacity & stroke as safe working practice and for long life of the jacks.
Roll Table Frame Press
Model No. |
Capacity |
Stroke |
Vertical Daylight |
Table Width |
Pump Height From GL |
Distance Between Hole |
Distance Between Column |
Width |
Depth |
Overall Width |
Overall Depth |
Distance |
Distance |
Working Height From GL |
Overall Height |
Electrical Motor Capacity |
Weight Approx |
|
| A1 min | A2 Max | B | C | D | E | F | G | H | J | K | L | M | N | |||||
WRF-50 |
50 |
330 |
150 | 940 | 520 | 300 | 200 | 730 | 950 | 125 | 1500 | 1600 | 200 | 270 | 750 | 2800 | 3 | 1100 |
WRF-100 |
100 |
330 |
160 | 1048 | 675 | 300 | 222 | 890 | 1150 | 180 | 1600 | 1675 | 205 | 270 | 815 | 3020 | 3 | 1750 |
WRF-200 |
200 |
330 |
280 | 1295 | 985 | 300 | 255 | 1220 | 1625 | 230 | 2200 | 2200 | 205 | 380 | 915 | 3200 | 5 | 4200 |
Features / Benefits
Table rolls smoothly on 4 bottom wheel over fabricated rail.
Table is lifted precisely by exclusive table lifting cylinder and pump.
Considering safety, frame is stationery and table rolls.
Double acting cylinder.
Lateral movement of cylinder for covering max. distance.
Vertical movement of (Moving) ) Bolster Table allows maximum accommodation of job height.
Hard chrome plated ram to resist scoring and corrosion.
Wiper to arrest ingress of foreign particles.
Working pressure 450-700 Bar.
Operated by Power pack
Effortless daylight adjustment hydraulically by main cylinder.
